SLIDE RAIL- IDLER WHEELS- AND TRACK ASSEMBLY для Arctic Cat Z 120 - 2000 года выпуска`
-
№АртикулНазвание
-
-7994-743 COMPLETE SKID FRAME ASSEMBLYCOMPLETE SKID FRAME ASSEMBLY
-
11604-561 RAIL, FORMEDRAIL, FORMED
-
21604-568 WEARSTRIP, SLIDE RAIL (BLACK)WEARSTRIP, SLIDE RAIL (BLACK)
-
38040-366 NUT, LOCKNUT, LOCK
-
48002-044 SCREW, CAPSCREW, CAP
-
58050-217 WASHERWASHER
-
60604-231 END CAP, SLIDE RAILEND CAP, SLIDE RAIL
-
70123-869 SCREW, MACHINESCREW, MACHINE
-
88002-131 SCREW, CAPSCREW, CAP
-
98051-247 WASHER, LOCKWASHER, LOCK
-
108050-247 WASHERWASHER
-
111604-565 SPACER, IDLER WHEEL, OUTERSPACER, IDLER WHEEL, OUTER
-
120300-180 WHEEL, IDLERWHEEL, IDLER
-
131604-564 SPACER, IDLER WHEEL, INNERSPACER, IDLER WHEEL, INNER
-
141604-555 AXLE, IDLER WHEELAXLE, IDLER WHEEL
-
150604-981 WHEEL, IDLER (REAR) (INC. 16, 19)WHEEL, IDLER (REAR) (INC. 16, 19)
-
160104-340 . INSERT, IDLER WHEEL, INNER. INSERT, IDLER WHEEL, INNER
-
170123-798 . RING, RETAINING. RING, RETAINING
-
180107-598 . BEARING. BEARING
-
190104-341 . INSERT, IDLER WHEEL, OUTER. INSERT, IDLER WHEEL, OUTER
-
201602-079 CLIP, GUIDECLIP, GUIDE
-
210604-968 BUSHING, SPACER IDLER WHEEL (REAR)BUSHING, SPACER IDLER WHEEL (REAR)
-
221604-562 AXLE, IDLER WHEEL (REAR)AXLE, IDLER WHEEL (REAR)
-
231604-563 SPACER, IDLER WHEEL (REAR)SPACER, IDLER WHEEL (REAR)
-
241604-661 HOUSING AXLE (REAR)HOUSING AXLE (REAR)
-
250604-206 ADJUSTER, TRACKADJUSTER, TRACK
-
260604-165 BUSHING IDLER WHEEL, ADJUSTMENT (REAR)BUSHING IDLER WHEEL, ADJUSTMENT (REAR)
-
278002-041 SCREW, CAPSCREW, CAP
-
280123-570 WASHERWASHER
-
298012-222 SCREW, CAPSCREW, CAP
-
300623-123 SCREW, CAPSCREW, CAP
-
318042-486 NUTNUT
-
328051-277 WASHER, LOCKWASHER, LOCK
-
330604-298 SPACER, TRACK ADJUSTERSPACER, TRACK ADJUSTER
-
348002-132 SCREW, CAPSCREW, CAP
-
358040-426 NUT, LOCKNUT, LOCK
-
361602-015 TRACK ASSEMBLY (INC. 20)TRACK ASSEMBLY (INC. 20)
