GAS TANK AND SEAT ASSEMBLY для Arctic Cat Pantera 550 - 2000 года выпуска

  • №
    Артикул
    Название
  • -
    0718-818 COMPLETE SEAT ASSEMBLY
    COMPLETE SEAT ASSEMBLY
  • 1
    0770-444 TANK, GAS/SEAT-BASE (INC. 2-5)
    TANK, GAS/SEAT-BASE (INC. 2-5)
  • 2
    0670-042 . OUTLET, TANK
    . OUTLET, TANK
  • 3
    0610-017 . HOSE, GASLINE - 100 FT
    . HOSE, GASLINE - 100 FT
  • 3
    0610-008 . HOSE, GASLINE - 25 FT
    . HOSE, GASLINE - 25 FT
  • 4
    0670-572 . VENT, GAS TANK
    . VENT, GAS TANK
  • 5
    0510-358 . STRAINER, GAS TANK
    . STRAINER, GAS TANK
  • 6
    0623-577 STAPLE, SEAT COVER
    STAPLE, SEAT COVER
  • 7
    0623-101 CLIP, ROUTING - SNAP-IN
    CLIP, ROUTING - SNAP-IN
  • 8
    0610-010 HOSE, VENT - 25 FT
    HOSE, VENT - 25 FT
  • 9
    0670-658 CAP, GAS TANK (INC. 10)
    CAP, GAS TANK (INC. 10)
  • 10
    0109-733 . SEAL, GAS CAP
    . SEAL, GAS CAP
  • 11
    0606-057 WIRE, SEAT
    WIRE, SEAT
  • 12
    0617-098 FOAM, SEAT-BASE - TAILLIGHT
    FOAM, SEAT-BASE - TAILLIGHT
  • 13
    8041-366 NUT, LOCK
    NUT, LOCK
  • 14
    8050-217 WASHER
    WASHER
  • 15
    8002-040 SCREW, CAP
    SCREW, CAP
  • 16
    0623-184 WASHER
    WASHER
  • 17
    0123-108 NUT, CAP
    NUT, CAP
  • 18
    0623-063 CLAMP, HOSE
    CLAMP, HOSE
  • 19
    1606-612 INSERT, SEAT FOAM
    INSERT, SEAT FOAM
  • 20
    1606-191 EXTENSION, TOOLBOX
    EXTENSION, TOOLBOX
  • 21
    0123-149 WASHER
    WASHER
  • 22
    0716-991 FOAM, SEAT CUSHION
    FOAM, SEAT CUSHION
  • 23
    1606-150 WIRE, SEAT
    WIRE, SEAT
  • 24
    0623-309 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 25
    1706-080 COVER, SEAT
    COVER, SEAT
  • 26
    8061-428 RIVET
    RIVET
