CYLINDER HEAD AND CAMSHAFT/VALVE ASSEMBLY для Arctic Cat ALTERRA 400 GREEN - 2017 года выпуска
-
№АртикулНазвание
-
10808-012 HEAD, CYLINDER - ASSEMBLY (INC. 2)HEAD, CYLINDER - ASSEMBLY (INC. 2)
-
23303-341 ...PIN, DOWEL...PIN, DOWEL
-
30826-115 SCREW, CAPSCREW, CAP
-
40830-155 GASKETGASKET
-
53304-918 BOLT FLANGE SH M6X1.0X110BOLT FLANGE SH M6X1.0X110
-
63303-386 BOLT, FLANGEBOLT, FLANGE
-
73307-053 BOLT, FLANGEBOLT, FLANGE
-
80826-136 BOLT, M6X1.0X30BOLT, M6X1.0X30
-
93303-384 BOLT, FLANGEBOLT, FLANGE
-
103306-787 PLUG, HEADPLUG, HEAD
-
110830-139 O-RINGO-RING
-
123303-383 BOLTBOLT
-
130808-111 CAP, INSPECTIONCAP, INSPECTION
-
140217-705 PLUG, SPARK (NGK CR8E)PLUG, SPARK (NGK CR8E)
-
153323-145 O-RINGO-RING
-
163313-843 MANIFOLD, INTAKE (INC. 15)MANIFOLD, INTAKE (INC. 15)
-
173304-189 BOLT, FLANGEBOLT, FLANGE
-
180423-380 CLAMP, HOSE - WORM (50-70MM X 9MM) - BLACKCLAMP, HOSE - WORM (50-70MM X 9MM) - BLACK
-
193303-656 BOLT, SEALING - 12 MMBOLT, SEALING - 12 MM
-
200809-287 CAMSHAFTCAMSHAFT
-
210809-165 C-RINGC-RING
-
220809-166 SPROCKETSPROCKET
-
230829-036 PIN, ALIGNMENTPIN, ALIGNMENT
-
240828-086 PLATE, RETAINERPLATE, RETAINER
-
250826-154 BOLT HEX 6X12BOLT HEX 6X12
-
260809-145 ARM, VALVE ROCKER - INTAKEARM, VALVE ROCKER - INTAKE
-
273304-007 SCREW, TAPPET ADJUSTINGSCREW, TAPPET ADJUSTING
-
283304-026 NUT, TAPPET ADJUSTINGNUT, TAPPET ADJUSTING
-
290809-149 ARM, VALVE ROCKER - EXHAUSTARM, VALVE ROCKER - EXHAUST
-
300809-151 SHAFT, ROCKER ARMSHAFT, ROCKER ARM
-
310830-143 WASHER, COMPRESSION - 14 X 19 X 1.35WASHER, COMPRESSION - 14 X 19 X 1.35
-
320831-053 PLUG, SHAFTPLUG, SHAFT
-
333303-044 COTTER, VALVECOTTER, VALVE
-
340809-142 RETAINER, SPRINGRETAINER, SPRING
-
350809-140 SPRING, VALVESPRING, VALVE
-
360809-190 SEAL, OILSEAL, OIL
-
370809-141 SEAT, SPRINGSEAT, SPRING
-
380809-188 VALVE, INTAKEVALVE, INTAKE
-
390809-189 VALVE, EXHAUSTVALVE, EXHAUST
-
400826-062 BOLT, ACS-HFH M10BOLT, ACS-HFH M10
-
410826-061 BOLT, ACS-HFH M10BOLT, ACS-HFH M10
-
420828-044 WASHERWASHER
-
430827-019 BOLT, STUDBOLT, STUD
-
443303-332 NUTNUT
-
450829-013 PIN, DOWELPIN, DOWEL
