REAR SUSPENSION ASSEMBLY для Arctic Cat WILDCAT TRAIL SE EPS TIMBER/ORANGE INTERNATIONAL [U2016WXT2POSH] - 2016 года выпуска

  • №
    Артикул
    Название
  • 1
    0504-874 SPRING, SUSPENSION - BLACK
    SPRING, SUSPENSION - BLACK
  • 2
    0404-306 SHOCK ABSORBER
    SHOCK ABSORBER
  • 3
    8409-055 SCREW, CAP
    SCREW, CAP
  • 4
    1423-334 NUT, LOCK
    NUT, LOCK
  • 5
    0504-898 A-ARM, REAR - UPPER RIGHT- ORANGE (INC. 6-8)
    A-ARM, REAR - UPPER RIGHT- ORANGE (INC. 6-8)
  • 5
    0504-899 A-ARM, REAR - UPPER LEFT - ORANGE (INC. 6-8)
    A-ARM, REAR - UPPER LEFT - ORANGE (INC. 6-8)
  • 6
    0403-305 ...SLEEVE
    ...SLEEVE
  • 7
    0403-264 ...BUSHING
    ...BUSHING
  • 8
    1423-204 ...SEAL
    ...SEAL
  • 9
    1423-266 SCREW, CAP
    SCREW, CAP
  • 10
    1504-036 A-ARM, REAR - LOWER RIGHT - ORANGE (INC. 7-8 AND 11)
    A-ARM, REAR - LOWER RIGHT - ORANGE (INC. 7-8 AND 11)
  • 10
    1504-037 A-ARM, REAR - LOWER LEFT - ORANGE (INC. 7-8 AND 11)
    A-ARM, REAR - LOWER LEFT - ORANGE (INC. 7-8 AND 11)
  • 11
    0403-250 ...SLEEVE
    ...SLEEVE
  • 12
    8413-090 SCREW, CAP
    SCREW, CAP
  • 13
    2502-349 KIT, HALFSHAFT (INC. 14-17)
    KIT, HALFSHAFT (INC. 14-17)
  • 14
    2436-112 ...REPAIR KIT, BOOT (INC. 15)
    ...REPAIR KIT, BOOT (INC. 15)
  • 15
    1441-988 ......CLIP, RETAINING
    ......CLIP, RETAINING
  • 16
    1402-885 PIN, DETENT
    PIN, DETENT
  • 17
    1402-889 CLIP, RETAINING
    CLIP, RETAINING
  • 18
    1402-963 O-RING
    O-RING
  • 19
    0504-681 KNUCKLE, REAR - ASSEMBLY (INC. 7-8, 11, AND 20-21)
    KNUCKLE, REAR - ASSEMBLY (INC. 7-8, 11, AND 20-21)
  • 20
    1402-809 ...BEARING
    ...BEARING
  • 21
    0423-423 ...RING, RETAINING
    ...RING, RETAINING
