CASE/BELT COOLING ASSEMBLY для Arctic Cat TRV 700 T3S RED [A2016TBT4ESTR] - 2016 года выпуска

  • №
    Артикул
    Название
  • 1
    0423-550 CLAMP
    CLAMP
  • 2
    0423-342 SCREW, SELF-TAPPING - .1875 X .75
    SCREW, SELF-TAPPING - .1875 X .75
  • 3
    0413-252 BOOT, INTAKE
    BOOT, INTAKE
  • 4
    0423-019 CLAMP
    CLAMP
  • 5
    0413-250 DUCT, INTAKE - LOWER
    DUCT, INTAKE - LOWER
  • 6
    0470-750 DUCT, AIR INTAKE - FRONT - UPPER
    DUCT, AIR INTAKE - FRONT - UPPER
  • 7
    0470-729 BOOT
    BOOT
  • 8
    0423-730 CLAMP
    CLAMP
  • 9
    0413-206 BOOT, COOLING BELT
    BOOT, COOLING BELT
  • 10
    0470-824 DUCT, BELT COOLING - AIR OUT (INC. THREE NO. 11 AND 12-13)
    DUCT, BELT COOLING - AIR OUT (INC. THREE NO. 11 AND 12-13)
  • 11
    0623-784 ...SCREW, SELF-TAPPING
    ...SCREW, SELF-TAPPING
  • 12
    0470-778 ...DUCT
    ...DUCT
  • 13
    0470-825 ...DUCT, AIR OUT - PRIMARY
    ...DUCT, AIR OUT - PRIMARY
