REAR SUSPENSION ASSEMBLY для Arctic Cat WILDCAT SPORT GREEN [U2015W6T4CUSZ] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    0404-498 SHOCK ABSORBER - RIGHT (INC. 2-9)
    SHOCK ABSORBER - RIGHT (INC. 2-9)
  • 1
    0404-499 SHOCK ABSORBER - LEFT (INC. 2-9)
    SHOCK ABSORBER - LEFT (INC. 2-9)
  • 2
    0403-506 ...BEARING
    ...BEARING
  • 3
    0403-507 ...CLIP
    ...CLIP
  • 4
    0403-504 ...O-RING
    ...O-RING
  • 5
    0403-508 ...SPACER
    ...SPACER
  • 6
    0403-500 ...NUT, RETAINER - SPRING
    ...NUT, RETAINER - SPRING
  • 7
    0403-501 ...SCREW, SET
    ...SCREW, SET
  • 8
    0403-502 ...RETAINER
    ...RETAINER
  • 9
    0403-503 ...CLIP
    ...CLIP
  • 10
    8409-055 SCREW, CAP
    SCREW, CAP
  • 11
    0504-991 SPRING, SUSPENSION - WHITE
    SPRING, SUSPENSION - WHITE
  • 12
    1423-266 SCREW, CAP
    SCREW, CAP
  • 13
    1423-334 NUT, LOCK
    NUT, LOCK
  • 14
    0504-980 A-ARM, REAR - UPPER - BLACK (INC. 15-17)
    A-ARM, REAR - UPPER - BLACK (INC. 15-17)
  • 15
    0404-503 ...SLEEVE
    ...SLEEVE
  • 16
    2402-077 ...BEARING
    ...BEARING
  • 17
    1423-287 ...SEAL
    ...SEAL
  • 18
    0504-976 A-ARM, REAR - LOWER RIGHT - BLACK (INC. 15-17 AND 19)
    A-ARM, REAR - LOWER RIGHT - BLACK (INC. 15-17 AND 19)
  • 18
    0504-977 A-ARM, REAR - LOWER LEFT - BLACK (INC. 15-17 AND 19)
    A-ARM, REAR - LOWER LEFT - BLACK (INC. 15-17 AND 19)
  • 19
    0404-501 ...SLEEVE
    ...SLEEVE
  • 20
    8413-090 SCREW, CAP
    SCREW, CAP
  • 21
    2502-355 KIT, HALFSHAFT (INC. 22-26)
    KIT, HALFSHAFT (INC. 22-26)
  • 22
    2436-111 ...REPAIR KIT, BOOT (INC. 23)
    ...REPAIR KIT, BOOT (INC. 23)
  • 23
    1441-988 ......CLIP, RETAINING
    ......CLIP, RETAINING
  • 24
    1402-884 ...PIN, DETENT
    ...PIN, DETENT
  • 25
    1402-963 ...O-RING
    ...O-RING
  • 26
    1402-890 ...CLIP, RETAINING
    ...CLIP, RETAINING
  • 27
    1504-066 KNUCKLE, REAR - ASSEMBLY (INC. 16-17, 19 AND 27-28)
    KNUCKLE, REAR - ASSEMBLY (INC. 16-17, 19 AND 27-28)
  • 28
    1402-809 ...BEARING
    ...BEARING
  • 29
    0423-423 RING, RETAINING
    RING, RETAINING
