REAR DOOR ASSEMBLY для Arctic Cat WILDCAT 4X WHITE [U2015WFW1POSW] (INTERNATIONAL) - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    2436-268 LATCH, RIGHT - ASSEMBLY (INC. 2-9) - BLUE
    LATCH, RIGHT - ASSEMBLY (INC. 2-9) - BLUE
  • 1
    2436-269 LATCH, LEFT - ASSEMBLY (INC. 2-9) - BLUE
    LATCH, LEFT - ASSEMBLY (INC. 2-9) - BLUE
  • 2
    4406-909 ...LATCH, ROTARY - LEFT
    ...LATCH, ROTARY - LEFT
  • 2
    4406-908 ...LATCH, ROTARY - RIGHT
    ...LATCH, ROTARY - RIGHT
  • 3
    4406-999 ...HANDLE, DOOR
    ...HANDLE, DOOR
  • 4
    1423-235 ...SPRING
    ...SPRING
  • 5
    8051-213 ...WASHER, LOCK
    ...WASHER, LOCK
  • 6
    1423-232 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 7
    1423-153 ...NUT, LOCK
    ...NUT, LOCK
  • 8
    1423-231 ...SCREW
    ...SCREW
  • 9
    4406-798 ...BRACKET, DOOR LATCH - RIGHT
    ...BRACKET, DOOR LATCH - RIGHT
  • 9
    4406-799 ...BRACKET, DOOR LATCH - LEFT
    ...BRACKET, DOOR LATCH - LEFT
  • 10
    4406-794 PLATE, STRIKER - RIGHT
    PLATE, STRIKER - RIGHT
  • 10
    4406-795 PLATE, STRIKER - LEFT
    PLATE, STRIKER - LEFT
  • 11
    1423-283 WASHER, LOCK
    WASHER, LOCK
  • 12
    1423-282 SCREW, CAP
    SCREW, CAP
  • 13
    1423-113 SCREW, MACHINE
    SCREW, MACHINE
  • 14
    4406-419 BUMPER, DOOR STOPPER
    BUMPER, DOOR STOPPER
  • 15
    4406-261 NET, RESTRAINT - LOWER
    NET, RESTRAINT - LOWER
  • 16
    8050-223 WASHER, FLAT
    WASHER, FLAT
  • 17
    1423-192 SCREW, SHOULDER
    SCREW, SHOULDER
  • 18
    1436-476 HINGE, DOOR - ASSEMBLY - RIGHT (INC. 19-20)
    HINGE, DOOR - ASSEMBLY - RIGHT (INC. 19-20)
  • 18
    1436-454 HINGE, DOOR - ASSEMBLY - LEFT (INC. 19-20)
    HINGE, DOOR - ASSEMBLY - LEFT (INC. 19-20)
  • 19
    1423-118 ...CIRCLIP
    ...CIRCLIP
  • 20
    0518-096 ...KIT, HINGE PIN
    ...KIT, HINGE PIN
  • 21
    5506-200 FRAME, DOOR - RIGHT
    FRAME, DOOR - RIGHT
  • 21
    5506-201 FRAME, DOOR - LEFT
    FRAME, DOOR - LEFT
  • 22
    5506-932 TUBE, SUPPORT - RIGHT
    TUBE, SUPPORT - RIGHT
  • 22
    5506-933 TUBE, SUPPORT - LEFT
    TUBE, SUPPORT - LEFT
  • 23
    4406-013 PLUG, HOLE
    PLUG, HOLE
  • 24
    1423-196 SCREW, SHOULDER
    SCREW, SHOULDER
  • 25
    4406-260 NET, RESTRAINT - UPPER
    NET, RESTRAINT - UPPER
  • 26
    0518-198 DOOR W/DECALS - RIGHT - BLACK (INC. 27-29)
    DOOR W/DECALS - RIGHT - BLACK (INC. 27-29)
  • 26
    0518-199 DOOR W/DECALS - LEFT - BLACK (INC. 27-29)
    DOOR W/DECALS - LEFT - BLACK (INC. 27-29)
  • 27
    4406-790 ...DOOR W/O DECALS - RIGHT - BLACK
    ...DOOR W/O DECALS - RIGHT - BLACK
  • 27
    4406-791 ...DOOR W/O DECALS - LEFT - BLACK
    ...DOOR W/O DECALS - LEFT - BLACK
  • 28
    4411-584 ...DECAL, DOOR - UPPER - RIGHT - WHITE
    ...DECAL, DOOR - UPPER - RIGHT - WHITE
  • 28
    4411-585 ...DECAL, DOOR - UPPER - LEFT - WHITE
    ...DECAL, DOOR - UPPER - LEFT - WHITE
  • 29
    4411-582 ...DECAL, DOOR - LOWER - RIGHT - WHITE
    ...DECAL, DOOR - LOWER - RIGHT - WHITE
  • 29
    4411-583 ...DECAL, DOOR - LOWER - LEFT - WHITE
    ...DECAL, DOOR - LOWER - LEFT - WHITE
  • 30
    0423-817 SCREW, MACHINE
    SCREW, MACHINE
  • 31
    0423-355 SCREW, SHOULDER
    SCREW, SHOULDER
  • 32
    8427-602 NUT, LOCK
    NUT, LOCK
  • 33
    0826-029 SCREW, MACHINE
    SCREW, MACHINE
