WHEEL AND TIRE ASSEMBLY для Arctic Cat TRV 700 LTD RED [A2015TCT1POSE] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    0423-557 SCREW, SHOULDER
    SCREW, SHOULDER
  • 2
    1436-808 KIT, DISC BRAKE
    KIT, DISC BRAKE
  • 3
    1502-462 HUB, WHEEL (INC. 4)
    HUB, WHEEL (INC. 4)
  • 4
    0402-974 ...STUD
    ...STUD
  • 5
    1502-462 HUB, WHEEL (INC. 4)
    HUB, WHEEL (INC. 4)
  • 5
    1502-464 HUB, WHEEL (REAR LEFT) (INC. 4)
    HUB, WHEEL (REAR LEFT) (INC. 4)
  • 6
    0423-607 NUT, CASTLE
    NUT, CASTLE
  • 7
    0423-407 PIN, COTTER
    PIN, COTTER
  • 8
    2402-068 WHEEL - FRONT - ALUMINUM (INC. 9)
    WHEEL - FRONT - ALUMINUM (INC. 9)
  • 9
    2402-084 ...CAP, WHEEL
    ...CAP, WHEEL
  • 10
    0402-064 STEM, VALVE - W/CAP (INC. 11)
    STEM, VALVE - W/CAP (INC. 11)
  • 11
    0402-064 ...STEM, VALVE - W/CAP
    ...STEM, VALVE - W/CAP
  • 12
    0423-618 NUT, LUG - CHROME
    NUT, LUG - CHROME
  • 13
    2402-250 TIRE - FRONT
    TIRE - FRONT
  • 14
    2402-069 WHEEL - REAR - ALUMINUM (INC. 9)
    WHEEL - REAR - ALUMINUM (INC. 9)
  • 15
    2402-097 TIRE - REAR
    TIRE - REAR
