REAR RACK ASSEMBLY для Arctic Cat TRV 700 LTD ORANGE [A2015TCT1POSU] (INTERNATIONAL) - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    2516-339 RACK, REAR - ASSEMBLY (PLASTIC) (INC. 2)
    RACK, REAR - ASSEMBLY (PLASTIC) (INC. 2)
  • 2
    1411-201 ...DECAL, WARNING - LOAD
    ...DECAL, WARNING - LOAD
  • 3
    8410-640 SCREW, CAP
    SCREW, CAP
  • 4
    8050-223 WASHER, FLAT
    WASHER, FLAT
  • 5
    0423-891 NUT, CAP
    NUT, CAP
  • 6
    2516-169 BASE, MRP - ASSEMBLY (INC. 7-11)
    BASE, MRP - ASSEMBLY (INC. 7-11)
  • 7
    0541-504 ...PIN - ASSEMBLY (INC. 8-10)
    ...PIN - ASSEMBLY (INC. 8-10)
  • 8
    0423-635 ......PIN, ROLL
    ......PIN, ROLL
  • 9
    0423-677 ......BUSHING, FLANGED
    ......BUSHING, FLANGED
  • 10
    0423-636 ......SPRING
    ......SPRING
  • 11
    0441-592 ...BUSHING
    ...BUSHING
  • 12
    8410-835 SCREW, CAP
    SCREW, CAP
  • 13
    0423-669 SPACER
    SPACER
  • 14
    0423-465 GROMMET
    GROMMET
  • 15
    0423-087 WASHER
    WASHER
  • 16
    8432-802 NUT, LOCK
    NUT, LOCK
  • 17
    0423-654 SCREW, SHOULDER
    SCREW, SHOULDER
  • 18
    2506-092 BRACKET, REAR FENDER - RIGHT
    BRACKET, REAR FENDER - RIGHT
  • 18
    2506-093 BRACKET, REAR FENDER - LEFT
    BRACKET, REAR FENDER - LEFT
  • 19
    8050-222 WASHER
    WASHER
  • 20
    8427-602 NUT, LOCK
    NUT, LOCK
