REAR SUSPENSION SHOCK ABSORBER для Arctic Cat PROWLER 700 HDX XT CAMO [U2015P7T1PUSH] - 2015 года выпуска

  • №
    Артикул
    Название
  • -
    0404-256 SHOCK ABSORBER - REAR - FOX FLOAT
    SHOCK ABSORBER - REAR - FOX FLOAT
  • 1
    2603-327 CAP, AIR VALVE
    CAP, AIR VALVE
  • 2
    2603-651 VALVE, AIR (INC. 3)
    VALVE, AIR (INC. 3)
  • 3
    1604-318 ...O-RING
    ...O-RING
  • 4
    0404-225 END CAP, SHOCK
    END CAP, SHOCK
  • 5
    1604-664 BEARING
    BEARING
  • 6
    3604-147 RING, RETAINING
    RING, RETAINING
  • 7
    2604-796 KIT, SEAL/CAP REBUILD
    KIT, SEAL/CAP REBUILD
  • 8
    0404-198 SLEEVE, WEAR
    SLEEVE, WEAR
  • 9
    2411-567 DECAL, SHOCK
    DECAL, SHOCK
  • 10
    0404-196 SPRING RETAINER, UPPER
    SPRING RETAINER, UPPER
  • 11
    0404-234 BODY, SHOCK - UPPER
    BODY, SHOCK - UPPER
  • 12
    3604-481 ROD, SHOCK
    ROD, SHOCK
  • 13
    2603-333 BEARING - ASSEMBLY
    BEARING - ASSEMBLY
  • 14
    1603-940 SCREW, SET
    SCREW, SET
  • 15
    1604-315 BALL, BLEED
    BALL, BLEED
  • 16
    0603-386 BUMPER, INTERNAL - TOP OUT
    BUMPER, INTERNAL - TOP OUT
  • 17
    0603-540 WASHER, TOP OUT - 1.125OD X 0.378ID X 0.093
    WASHER, TOP OUT - 1.125OD X 0.378ID X 0.093
  • 18
    2603-224 VALVE, 0.620 X 0.015 IN.
    VALVE, 0.620 X 0.015 IN.
  • 19
    0603-878 VALVE, 0.700 X 0.012 IN.
    VALVE, 0.700 X 0.012 IN.
  • 20
    0603-879 VALVE, 0.800 X 0.012 IN.
    VALVE, 0.800 X 0.012 IN.
  • 21
    0603-338 VALVE, 0.900 X 0.010 IN.
    VALVE, 0.900 X 0.010 IN.
  • 22
    0603-341 VALVE, 1.000 X 0.010 IN.
    VALVE, 1.000 X 0.010 IN.
  • 23
    0603-344 VALVE, 1.100 X 0.010 IN.
    VALVE, 1.100 X 0.010 IN.
  • 24
    0603-347 VALVE, 1.250 X 0.010 IN.
    VALVE, 1.250 X 0.010 IN.
  • 25
    0603-342 VALVE, 1.100 X 0.006 (3/8 ID)
    VALVE, 1.100 X 0.006 (3/8 ID)
  • 26
    2603-936 VALVE RING, 1.250 X 0.008 IN.
    VALVE RING, 1.250 X 0.008 IN.
  • 27
    0603-349 VALVE, 1.300 X 0.008 IN.
    VALVE, 1.300 X 0.008 IN.
  • 28
    0603-208 PISTON, 0.078 IN. - ORIFICE
    PISTON, 0.078 IN. - ORIFICE
  • 29
    0603-346 VALVE, 1.250 X 0.008 (3/8 ID)
    VALVE, 1.250 X 0.008 (3/8 ID)
  • 30
    0603-345 VALVE, 1.250 X 0.006 IN.
    VALVE, 1.250 X 0.006 IN.
  • 31
    0603-336 VALVE, 0.900 X 0.006 IN.
    VALVE, 0.900 X 0.006 IN.
  • 32
    0603-343 VALVE, 1.100 X 0.008 IN.
    VALVE, 1.100 X 0.008 IN.
  • 33
    0603-335 VALVE, 0.800 X 0.010 IN.
    VALVE, 0.800 X 0.010 IN.
  • 34
    0603-389 WASHER, BACKUP
    WASHER, BACKUP
  • 35
    0603-301 NUT, CAP - FOX SHOCK
    NUT, CAP - FOX SHOCK
  • 36
    0404-230 PISTON, FLOATING
    PISTON, FLOATING
  • 37
    0404-227 BODY, SHOCK - LOWER
    BODY, SHOCK - LOWER
  • 38
    2603-337 BALL, AIR VALVE
    BALL, AIR VALVE
  • 39
    2603-338 SCREW, SET
    SCREW, SET
  • 40
    1604-428 PLUG, RUBBER - VALVE
    PLUG, RUBBER - VALVE
  • 41
    0404-197 SPRING RETAINER, LOWER
    SPRING RETAINER, LOWER
  • 42
    2603-245 RETAINER
    RETAINER
  • 43
    5639-530 OIL, SHOCK - 1 QT
    OIL, SHOCK - 1 QT
  • 44
    4639-012 FLUID, FLOAT SHOCK - 8 OZ
    FLUID, FLOAT SHOCK - 8 OZ
