SECONDARY TRANSMISSION ASSEMBLY для Arctic Cat 500 GREEN [A2015ICK4CUSG] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    0828-081 WASHER, THRUST
    WASHER, THRUST
  • 2
    0822-061 GEAR, REVERSE IDLE
    GEAR, REVERSE IDLE
  • 3
    0822-065 BUSHING
    BUSHING
  • 4
    0822-064 SHAFT, REVERSE IDLE
    SHAFT, REVERSE IDLE
  • 5
    0822-029 SPACER
    SPACER
  • 6
    0822-128 DRIVESHAFT
    DRIVESHAFT
  • 7
    3306-849 COUNTERSHAFT ASSEMBLY (INC. 8-18)
    COUNTERSHAFT ASSEMBLY (INC. 8-18)
  • 8
    3306-844 ...GEAR SELECT, REVERSE
    ...GEAR SELECT, REVERSE
  • 9
    3304-147 ...CIRCLIP, EXTERNAL - 25 MM
    ...CIRCLIP, EXTERNAL - 25 MM
  • 10
    3304-045 ...WASHER
    ...WASHER
  • 11
    0832-038 ...BEARING
    ...BEARING
  • 12
    0822-062 ...BUSHING
    ...BUSHING
  • 13
    3306-845 ...GEAR, REVERSE DRIVEN
    ...GEAR, REVERSE DRIVEN
  • 14
    3306-846 ...GEAR, DRIVEN - LOW
    ...GEAR, DRIVEN - LOW
  • 15
    3306-847 ...GEAR SELECT, SLIDING
    ...GEAR SELECT, SLIDING
  • 16
    3304-044 ...WASHER, THRUST - 25 MM
    ...WASHER, THRUST - 25 MM
  • 17
    3306-848 ...GEAR, DRIVEN - HIGH
    ...GEAR, DRIVEN - HIGH
  • 18
    0822-025 ...COUNTERSHAFT
    ...COUNTERSHAFT
  • 19
    0822-028 GEAR, DRIVE
    GEAR, DRIVE
  • 20
    0822-023 SHAFT, OUTPUT
    SHAFT, OUTPUT
  • 21
    3304-198 BEARING
    BEARING
  • 22
    3303-395 PIN, DOWEL
    PIN, DOWEL
  • 23
    0830-156 GASKET, HOUSING
    GASKET, HOUSING
  • 24
    0822-105 HOUSING, SPEEDOMETER SENSOR
    HOUSING, SPEEDOMETER SENSOR
  • 25
    3303-382 BOLT, FLANGE
    BOLT, FLANGE
  • 26
    3313-172 SENSOR, SPEEDOMETER
    SENSOR, SPEEDOMETER
  • 27
    0830-155 GASKET
    GASKET
  • 28
    3303-387 SCREW, CAP
    SCREW, CAP
