GEAR SHIFTING ASSEMBLY для Arctic Cat 450 RED [A2015IRK4CUSR] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    0818-126 DRUM, GEAR SHIFT - ASSEMBLY (INC. 2-8 AND TWO NO. 9)
    DRUM, GEAR SHIFT - ASSEMBLY (INC. 2-8 AND TWO NO. 9)
  • 2
    0818-125 ...SHAFT, SHIFT
    ...SHAFT, SHIFT
  • 3
    3304-439 ...PIN, DOWEL
    ...PIN, DOWEL
  • 4
    3304-147 ...CIRCLIP, EXTERNAL - 25 MM
    ...CIRCLIP, EXTERNAL - 25 MM
  • 5
    0818-060 ...SPRING
    ...SPRING
  • 6
    0818-117 ...CAM, GEAR SHIFT
    ...CAM, GEAR SHIFT
  • 7
    0831-016 ...C-RING
    ...C-RING
  • 8
    0818-116 ...CAM, REVERSE
    ...CAM, REVERSE
  • 9
    0828-079 ...WASHER
    ...WASHER
  • 10
    0828-081 WASHER, THRUST
    WASHER, THRUST
  • 11
    0828-080 WASHER, THRUST
    WASHER, THRUST
  • 12
    0818-061 PLATE, GEAR SHIFT CAM
    PLATE, GEAR SHIFT CAM
  • 13
    3304-569 SCREW, CAP
    SCREW, CAP
  • 14
    0828-084 WASHER
    WASHER
  • 15
    0818-113 SHAFT, SUB-GEAR SHIFT (INC. 16)
    SHAFT, SUB-GEAR SHIFT (INC. 16)
  • 16
    0831-056 ...RING, RETAINING
    ...RING, RETAINING
  • 17
    0830-179 SEAL
    SEAL
  • 18
    3306-259 SWITCH, GEAR POSITION
    SWITCH, GEAR POSITION
  • 19
    3306-316 ARM, SELECT
    ARM, SELECT
  • 20
    3304-551 BOLT, FLANGE - 6 X 22
    BOLT, FLANGE - 6 X 22
  • 21
    0828-083 WASHER
    WASHER
  • 22
    0818-084 STOPPER, CAM
    STOPPER, CAM
  • 23
    0818-062 SUPPORT, CAM STOPPER
    SUPPORT, CAM STOPPER
  • 24
    0818-109 SPRING
    SPRING
  • 25
    0828-082 WASHER
    WASHER
  • 26
    3304-654 NUT, FLANGE - 6 MM
    NUT, FLANGE - 6 MM
  • 27
    0818-021 SHAFT, SHIFT FORK
    SHAFT, SHIFT FORK
  • 28
    0818-088 FORK, SHIFT
    FORK, SHIFT
