KICK STARTER AND COOLING DUCT ASSEMBLY для Arctic Cat 150 UTILITY RED [A2015KYC2BOSR] (INTERNATIONAL) - 2015 года выпуска
-
№АртикулНазвание
-
13303-549 ARM, KICK STARTER - ASSEMBLY (INC. 2-3)ARM, KICK STARTER - ASSEMBLY (INC. 2-3)
-
23305-195 ...WASHER...WASHER
-
33305-247 ...E-RING...E-RING
-
43304-551 BOLT, FLANGE - 6 X 22BOLT, FLANGE - 6 X 22
-
53305-235 DUCT, COOLINGDUCT, COOLING
-
63303-635 CLAMP W/SCREWCLAMP W/SCREW
-
73303-636 CLAMP W/SCREWCLAMP W/SCREW
-
83305-234 DUCT, COOLINGDUCT, COOLING
