WIRING HARNESS ASSEMBLY для Arctic Cat TRV 400 Core 4x4 [A2014TBG4BOSR] (INTERNATIONAL) - 2014 года выпуска

  • №
    Артикул
    Название
  • 1
    0486-464 HARNESS, MAIN (INC. 2-8)
    HARNESS, MAIN (INC. 2-8)
  • 2
    0486-164 ...TETHER, ACCESSORY CONNECTOR
    ...TETHER, ACCESSORY CONNECTOR
  • 3
    0430-085 ...COVER, FUSE BLOCK
    ...COVER, FUSE BLOCK
  • 4
    0430-045 ...RELAY (4-PIN) - 20 AMP
    ...RELAY (4-PIN) - 20 AMP
  • 5
    0430-032 ...FUSE - 10 AMP
    ...FUSE - 10 AMP
  • 5
    0430-031 ...FUSE - 15 AMP
    ...FUSE - 15 AMP
  • 5
    0430-030 ...FUSE - 30 AMP
    ...FUSE - 30 AMP
  • 6
    0430-037 ...HOLDER, FUSE
    ...HOLDER, FUSE
  • 7
    0430-086 ...SEAL
    ...SEAL
  • 8
    2411-078 ...DECAL, FUSE BLOCK
    ...DECAL, FUSE BLOCK
  • 9
    1436-415 REPAIR KIT, CONNECTOR - LCD GAUGE
    REPAIR KIT, CONNECTOR - LCD GAUGE
  • 10
    1436-289 REPAIR KIT, CONNECTOR - HEADLIGHT
    REPAIR KIT, CONNECTOR - HEADLIGHT
  • 11
    0123-788 TIE, CABLE - 8 IN.
    TIE, CABLE - 8 IN.
  • 12
    0445-064 CABLE, SOLENOID/STARTER (INC. 13)
    CABLE, SOLENOID/STARTER (INC. 13)
  • 13
    0645-019 ...BOOT, TERMINAL
    ...BOOT, TERMINAL
  • 14
    0645-327 BOOT, TERMINAL
    BOOT, TERMINAL
  • 15
    0445-062 CABLE, BATTERY/SOLENOID
    CABLE, BATTERY/SOLENOID
  • 16
    0623-038 NUT W/WASHER
    NUT W/WASHER
  • 17
    0445-058 SOLENOID
    SOLENOID
  • 18
    8476-625 SCREW, MACHINE
    SCREW, MACHINE
  • 19
    0412-291 FOIL, PROTECTIVE
    FOIL, PROTECTIVE
  • 20
    1406-787 TRAY, ELECTRICAL
    TRAY, ELECTRICAL
  • 21
    0623-362 RIVET, REINSTALLABLE
    RIVET, REINSTALLABLE
  • 22
    3313-436 CDI UNIT
    CDI UNIT
  • 23
    0409-089 SWITCH, BRAKE - ASSEMBLY
    SWITCH, BRAKE - ASSEMBLY
  • 24
    0123-903 CABLE TIE - 11.5 IN.
    CABLE TIE - 11.5 IN.
  • 25
    0824-037 REGULATOR, VOLTAGE
    REGULATOR, VOLTAGE
  • 26
    0445-079 CABLE, BATTERY/GROUND
    CABLE, BATTERY/GROUND
  • 27
    3323-216 COIL, IGNITION - ASSEMBLY (INC. 28)
    COIL, IGNITION - ASSEMBLY (INC. 28)
  • 28
    3313-695 ...CAP, SPARK PLUG
    ...CAP, SPARK PLUG
  • 29
    8470-525 SCREW, MACHINE
    SCREW, MACHINE
  • 30
    8427-502 NUT, LOCK
    NUT, LOCK
