HYDRAULIC BRAKE ASSEMBLY для Arctic Cat PROWLER 700 HDX 4X4 GREEN [U2014P5T1POSN] (INTERNATIONAL) - 2014 года выпуска

  • №
    Артикул
    Название
  • 1
    1402-893 HOSE, REAR BRAKE
    HOSE, REAR BRAKE
  • 2
    0623-038 NUT W/WASHER
    NUT W/WASHER
  • 3
    8476-616 SCREW, MACHINE
    SCREW, MACHINE
  • 4
    1502-692 LEVER, BRAKE
    LEVER, BRAKE
  • 5
    8408-822 SCREW, CAP
    SCREW, CAP
  • 6
    0623-044 WASHER
    WASHER
  • 7
    1602-213 O-RING
    O-RING
  • 8
    0502-786 CYLINDER, MASTER BRAKE - ASSEMBLY (INC. 9-11)
    CYLINDER, MASTER BRAKE - ASSEMBLY (INC. 9-11)
  • 9
    0402-592 ...NUT
    ...NUT
  • 10
    1402-520 ...CLEVIS
    ...CLEVIS
  • 11
    0405-225 ...CAP, RESERVOIR
    ...CAP, RESERVOIR
  • 12
    1402-377 PIN, CLEVIS
    PIN, CLEVIS
  • 13
    0117-868 PIN, COTTER
    PIN, COTTER
  • 14
    8050-217 WASHER
    WASHER
  • 15
    0502-785 SPRING, BRAKE SWITCH
    SPRING, BRAKE SWITCH
  • 16
    8424-802 NUT
    NUT
  • 17
    8408-860 SCREW, CAP
    SCREW, CAP
  • 18
    0423-178 WASHER, CRUSH
    WASHER, CRUSH
  • 19
    0423-413 BOLT, BANJO-FITTING
    BOLT, BANJO-FITTING
  • 20
    0423-610 BOLT, DOUBLE BANJO-FITTING
    BOLT, DOUBLE BANJO-FITTING
  • 21
    1402-290 HOSE, BRAKE - FRONT RIGHT
    HOSE, BRAKE - FRONT RIGHT
  • 22
    1402-389 HOSE, BRAKE - FRONT LEFT
    HOSE, BRAKE - FRONT LEFT
  • 23
    8408-826 SCREW, CAP
    SCREW, CAP
  • 24
    1502-730 CALIPER, BRAKE - FRONT RIGHT (INC. 25-31)
    CALIPER, BRAKE - FRONT RIGHT (INC. 25-31)
  • 24
    1502-731 CALIPER, BRAKE - FRONT LEFT (INC. 25-31)
    CALIPER, BRAKE - FRONT LEFT (INC. 25-31)
  • 24
    1436-422 CALIPER, BRAKE - REAR RIGHT (INC. 25-32)
    CALIPER, BRAKE - REAR RIGHT (INC. 25-32)
  • 24
    1436-423 CALIPER, BRAKE - REAR LEFT (INC. 25-32)
    CALIPER, BRAKE - REAR LEFT (INC. 25-32)
  • 25
    1436-160 ...HOUSING, CALIPER - ASSEMBLY - FRONT RIGHT
    ...HOUSING, CALIPER - ASSEMBLY - FRONT RIGHT
  • 25
    1436-161 ...HOUSING, CALIPER - ASSEMBLY - FRONT LEFT
    ...HOUSING, CALIPER - ASSEMBLY - FRONT LEFT
  • 25
    1436-160 ...HOUSING, CALIPER - ASSEMBLY - REAR RIGHT
    ...HOUSING, CALIPER - ASSEMBLY - REAR RIGHT
  • 25
    1436-161 ...HOUSING, CALIPER - ASSEMBLY - REAR LEFT
    ...HOUSING, CALIPER - ASSEMBLY - REAR LEFT
  • 26
    0502-606 ......PISTON/SEAL SET (INC. 27)
    ......PISTON/SEAL SET (INC. 27)
  • 27
    0502-607 .........SEAL SET
    .........SEAL SET
  • 28
    0502-609 ......VALVE, BLEED
    ......VALVE, BLEED
  • 29
    0502-608 ...O-RING, GUIDE - SET
    ...O-RING, GUIDE - SET
  • 30
    0502-960 ...BRACKET ASSEMBLY - FRONT
    ...BRACKET ASSEMBLY - FRONT
  • 30
    0502-605 ...BRACKET ASSEMBLY - REAR
    ...BRACKET ASSEMBLY - REAR
  • 31
    1502-694 ...PAD, BRAKE - SET
    ...PAD, BRAKE - SET
  • 32
    8408-821 ...SCREW, CAP
    ...SCREW, CAP
  • 33
    5639-848 FLUID, BRAKE - 12 OZ
    FLUID, BRAKE - 12 OZ
