RIGHT CRANKCASE AND COVER ASSEMBLY для Arctic Cat 90 Utility [A2014KUB2BUSR] - 2014 года выпуска

  • №
    Артикул
    Название
  • 1
    3305-910 COVER, FAN - ASSEMBLY
    COVER, FAN - ASSEMBLY
  • 2
    3305-651 ...SCREW, SELF-TAPPING
    ...SCREW, SELF-TAPPING
  • 3
    2411-052 ...DECAL, SHIFT
    ...DECAL, SHIFT
  • 4
    3303-384 BOLT FLANGE
    BOLT FLANGE
  • 5
    3303-382 BOLT FLANGE
    BOLT FLANGE
  • 6
    3303-075 FAN, COOLING
    FAN, COOLING
  • 7
    3303-333 NUT
    NUT
  • 8
    3303-127 ROTOR/FLYWHEEL (A) - D402
    ROTOR/FLYWHEEL (A) - D402
  • 8
    3303-414 ROTOR/FLYWHEEL (B) - D406
    ROTOR/FLYWHEEL (B) - D406
  • 8
    3303-415 ROTOR/FLYWHEEL (C) - D414
    ROTOR/FLYWHEEL (C) - D414
  • 9
    3303-383 SCREW, CAP
    SCREW, CAP
  • 10
    3304-641 STATOR - ASSEMBLY (O) - D402
    STATOR - ASSEMBLY (O) - D402
  • 10
    3305-254 STATOR - ASSEMBLY (A) - D406
    STATOR - ASSEMBLY (A) - D406
  • 10
    3305-256 STATOR - ASSEMBLY (B) - D414
    STATOR - ASSEMBLY (B) - D414
  • 11
    3304-580 BOLT FLANGE 6X85
    BOLT FLANGE 6X85
  • 12
    3303-308 SCREW, CAP
    SCREW, CAP
  • 13
    3303-390 BOLT FLANGE
    BOLT FLANGE
  • 14
    3303-007 COVER, CRANKCASE
    COVER, CRANKCASE
  • 15
    3303-050 GAUGE, OIL LEVEL - ASSEMBLY (INC. 16)
    GAUGE, OIL LEVEL - ASSEMBLY (INC. 16)
  • 16
    3304-102 ...O-RING
    ...O-RING
  • 17
    3303-012 GASKET, CRANKCASE COVER
    GASKET, CRANKCASE COVER
  • 18
    3303-691 SCREEN, FILTER
    SCREEN, FILTER
  • 19
    3303-692 SPRING
    SPRING
  • 20
    3304-096 O-RING
    O-RING
  • 21
    3303-021 CAP, INSPECTION
    CAP, INSPECTION
  • 22
    3303-296 SEAL, OIL
    SEAL, OIL
  • 23
    3303-247 BOLT, STUD
    BOLT, STUD
  • 24
    3303-400 CRANKCASE (INC. 25-27)
    CRANKCASE (INC. 25-27)
  • 25
    3303-402 ...BUSHING, RUBBER - ENGINE MOUNT
    ...BUSHING, RUBBER - ENGINE MOUNT
  • 26
    3304-065 ...PLUG
    ...PLUG
  • 28
    3303-003 GASKET, CRANKCASE
    GASKET, CRANKCASE
  • 29
    3305-806 CASE, TRANSMISSION
    CASE, TRANSMISSION
  • 30
    3305-807 GASKET, TRANSMISSION CASE
    GASKET, TRANSMISSION CASE
  • 31
    3303-342 PIN, DOWEL
    PIN, DOWEL
  • 32
    3303-596 BEARING
    BEARING
  • 33
    3305-821 BEARING
    BEARING
  • 34
    3304-909 BEARING
    BEARING
  • 35
    3305-808 SEAL, OIL
    SEAL, OIL
  • 36
    3303-615 BOLT FLANGE 8*40
    BOLT FLANGE 8*40
  • 37
    3304-052 PLUG, FILL
    PLUG, FILL
  • 38
    3305-468 SCREW, CAP
    SCREW, CAP
  • 39
    3303-387 SCREW, CAP
    SCREW, CAP
  • 40
    3303-341 PIN, DOWEL
    PIN, DOWEL
