FRONT SUSPENSION ASSEMBLY для Arctic Cat 150 Utility [A2014KYC2BUSR] - 2014 года выпуска

  • №
    Артикул
    Название
  • 1
    3305-208 A-ARM ASSEMBLY - RIGHT (INC. 2)
    A-ARM ASSEMBLY - RIGHT (INC. 2)
  • 1
    3305-209 A-ARM ASSEMBLY - LEFT (INC. 2)
    A-ARM ASSEMBLY - LEFT (INC. 2)
  • 2
    3303-965 ...BUSHING
    ...BUSHING
  • 3
    3304-182 SCREW, CAP
    SCREW, CAP
  • 4
    3304-031 NUT
    NUT
  • 5
    3305-937 SHOCK/SPRING ASSEMBLY - BLACK
    SHOCK/SPRING ASSEMBLY - BLACK
  • 6
    3303-376 SCREW, CAP
    SCREW, CAP
  • 7
    3305-724 PIN, COTTER
    PIN, COTTER
  • 8
    3305-211 NUT, LOCK
    NUT, LOCK
  • 9
    3305-107 WASHER
    WASHER
  • 10
    3305-202 SCREW, CAP
    SCREW, CAP
  • 11
    3305-198 KNUCKLE - ASSEMBLY - RIGHT (INC. 12-15)
    KNUCKLE - ASSEMBLY - RIGHT (INC. 12-15)
  • 11
    3305-203 KNUCKLE - ASSEMBLY - LEFT (INC. 12-15)
    KNUCKLE - ASSEMBLY - LEFT (INC. 12-15)
  • 12
    3305-201 ...CAP
    ...CAP
  • 13
    3305-199 ...BUSHING
    ...BUSHING
  • 14
    3303-393 ...FITTING, GREASE
    ...FITTING, GREASE
  • 15
    3305-200 ...AXLE
    ...AXLE
