FRONT SUSPENSION SHOCK ABSORBER для Arctic Cat Wildcat X - RED [U2013WSW1POSE] (INTERATIONAL) - 2013 года выпуска

  • №
    Артикул
    Название
  • -
    0403-343 COMPLETE SHOCK ABSORBER
    COMPLETE SHOCK ABSORBER
  • 1
    0403-367 EYELET
    EYELET
  • 2
    1604-664 BEARING
    BEARING
  • 3
    3604-147 RING, RETAINING
    RING, RETAINING
  • 4
    0603-680 O-RING
    O-RING
  • 5
    0403-347 SPACER
    SPACER
  • 6
    0403-370 ROD, SHOCK
    ROD, SHOCK
  • 7
    0403-361 BUMPER, SHOCK
    BUMPER, SHOCK
  • 8
    0403-379 END CAP, SHOCK
    END CAP, SHOCK
  • 9
    0403-393 KIT, SEAL/CAP REBUILD
    KIT, SEAL/CAP REBUILD
  • 10
    0604-992 RING, RETAINING
    RING, RETAINING
  • 11
    0403-371 SPACER
    SPACER
  • 12
    2604-449 WASHER, TOP OUT
    WASHER, TOP OUT
  • 13
    0403-382 VALVE, 0.900 X 0.012 IN.
    VALVE, 0.900 X 0.012 IN.
  • 14
    2604-481 VALVE, 0.950 X 0.012 IN.
    VALVE, 0.950 X 0.012 IN.
  • 15
    2604-487 VALVE, 1.100 X 0.012 IN.
    VALVE, 1.100 X 0.012 IN.
  • 16
    2604-687 VALVE, 1.250 X 0.012 IN.
    VALVE, 1.250 X 0.012 IN.
  • 17
    2604-493 VALVE, 1.350 X 0.012 IN.
    VALVE, 1.350 X 0.012 IN.
  • 18
    2604-498 VALVE, 1.425 X 0.012 IN.
    VALVE, 1.425 X 0.012 IN.
  • 19
    2604-503 VALVE, 1.600 X 0.012 IN.
    VALVE, 1.600 X 0.012 IN.
  • 20
    0403-381 VALVE, 1.250 X 0.004 IN.
    VALVE, 1.250 X 0.004 IN.
  • 21
    2604-501 VALVE, 1.600 X 0.008 IN.
    VALVE, 1.600 X 0.008 IN.
  • 22
    0403-385 VALVE, 1.600 X 0.006 IN.
    VALVE, 1.600 X 0.006 IN.
  • 23
    0403-394 PISTON, HIGH-FLOW
    PISTON, HIGH-FLOW
  • 24
    2604-496 VALVE, 1.425 X 0.008 IN.
    VALVE, 1.425 X 0.008 IN.
  • 25
    0403-384 VALVE, 0.750 X 0.008 IN.
    VALVE, 0.750 X 0.008 IN.
  • 26
    2604-491 VALVE, 1.350 X 0.008 IN.
    VALVE, 1.350 X 0.008 IN.
  • 27
    2604-685 VALVE, 1.250 X 0.008 IN.
    VALVE, 1.250 X 0.008 IN.
  • 28
    2604-485 VALVE, 1.100 X 0.008 IN.
    VALVE, 1.100 X 0.008 IN.
  • 29
    2604-479 VALVE, 0.950 X 0.008 IN.
    VALVE, 0.950 X 0.008 IN.
  • 30
    2604-473 VALVE, 0.800 X 0.008 IN.
    VALVE, 0.800 X 0.008 IN.
  • 31
    0403-383 WASHER, TOP OUT
    WASHER, TOP OUT
  • 32
    3604-184 WASHER, BACKUP
    WASHER, BACKUP
  • 33
    0403-362 NUT
    NUT
  • 34
    0403-366 BODY, SHOCK
    BODY, SHOCK
  • 35
    0403-352 SEAT, SPRING
    SEAT, SPRING
  • 36
    0403-350 NUT, ADJUSTER
    NUT, ADJUSTER
  • 37
    0403-348 COLLAR, LOCKING - ADJUSTER NUT
    COLLAR, LOCKING - ADJUSTER NUT
  • 38
    0403-363 DECAL, SHOCK
    DECAL, SHOCK
  • 39
    0403-376 END CAP, SHOCK/RESERVOIR
    END CAP, SHOCK/RESERVOIR
  • 40
    0403-369 RESERVOIR
    RESERVOIR
  • 41
    0403-377 PISTON, INTERNAL FLOATING (INC. 42-43)
    PISTON, INTERNAL FLOATING (INC. 42-43)
  • 42
    1604-316 ...SCREW, MACHINE W/O-RING (INC. 43)
    ...SCREW, MACHINE W/O-RING (INC. 43)
  • 43
    1604-425 ......O-RING
    ......O-RING
  • 44
    3604-517 END CAP, RESERVOIR (INC. 45-47)
    END CAP, RESERVOIR (INC. 45-47)
  • 45
    1604-428 ...PLUG
    ...PLUG
  • 46
    2603-338 ...SCREW, SET
    ...SCREW, SET
  • 47
    2603-337 ...BALL
    ...BALL
  • 48
    0403-380 PISTON, CONCENTRIC - DAMPING ADJUSTER
    PISTON, CONCENTRIC - DAMPING ADJUSTER
  • 49
    5639-530 OIL, SHOCK - 1 QT
    OIL, SHOCK - 1 QT
  • 50
    0403-345 RETAINER, SPRING
    RETAINER, SPRING
