AIR INTAKE ASSEMBLY для Arctic Cat Super Duty Diesel 700 4x4 [A2013TBT4DUSG] - 2013 года выпуска

  • №
    Артикул
    Название
  • 1
    2406-509 SHROUD, SPLASH
    SHROUD, SPLASH
  • 2
    0623-362 RIVET, REINSTALLABLE
    RIVET, REINSTALLABLE
  • 3
    0413-091 DIVERTER, AIR - TOP
    DIVERTER, AIR - TOP
  • 4
    0413-093 DIVERTER, AIR - BOTTOM
    DIVERTER, AIR - BOTTOM
  • 5
    0423-832 CLAMP
    CLAMP
  • 6
    0470-618 DUCT, AIR INTAKE
    DUCT, AIR INTAKE
  • 7
    0470-991 FILTER, AIR - ASSEMBLY (INC. 8-11)
    FILTER, AIR - ASSEMBLY (INC. 8-11)
  • 8
    1470-011 ...CAP, AIR FILTER
    ...CAP, AIR FILTER
  • 9
    0470-619 ...FILTER, AIR
    ...FILTER, AIR
  • 10
    0470-620 ...ELEMENT, AIR FILTER
    ...ELEMENT, AIR FILTER
  • 11
    0470-628 ...BRACKET, MOUNTING - AIR FILTER
    ...BRACKET, MOUNTING - AIR FILTER
  • 12
    8476-620 SCREW, MACHINE
    SCREW, MACHINE
  • 13
    8050-222 WASHER
    WASHER
  • 14
    2506-082 BRACKET, MOUNTING - AIR FILTER
    BRACKET, MOUNTING - AIR FILTER
  • 15
    8476-616 SCREW, MACHINE
    SCREW, MACHINE
  • 16
    0423-066 CLAMP
    CLAMP
  • 17
    0470-621 DUCT, ENGINE INTAKE
    DUCT, ENGINE INTAKE
