REAR RACK- BODY PANEL- AND FOOTWELL ASSEMBLIES для Arctic Cat 450 RED [A2012ICK4CUSR] - 2012 года выпуска

  • №
    Артикул
    Название
  • 1
    2506-124 RACK, REAR - ASSEMBLY (INC. 2-3)
    RACK, REAR - ASSEMBLY (INC. 2-3)
  • 2
    0411-648 ...DECAL, WARNING - LOAD
    ...DECAL, WARNING - LOAD
  • 3
    0441-592 ...BUSHING
    ...BUSHING
  • 4
    8410-830 SCREW, CAP
    SCREW, CAP
  • 5
    0423-669 SPACER
    SPACER
  • 6
    0423-465 GROMMET
    GROMMET
  • 7
    8432-802 NUT, LOCK
    NUT, LOCK
  • 8
    0423-654 SCREW, SHOULDER
    SCREW, SHOULDER
  • 9
    8050-222 WASHER
    WASHER
  • 10
    0423-540 NUT, LOCK
    NUT, LOCK
  • 11
    0411-965 DECAL, "SPEEDRACK"
    DECAL, "SPEEDRACK"
  • 12
    2406-280 FOOTWELL - RIGHT
    FOOTWELL - RIGHT
  • 12
    2516-385 FOOTWELL - LEFT
    FOOTWELL - LEFT
  • 13
    0423-419 SCREW, MACHINE
    SCREW, MACHINE
  • 14
    1506-125 FOOTPEG
    FOOTPEG
  • 15
    0423-355 SCREW, SHOULDER
    SCREW, SHOULDER
  • 16
    8424-602 NUT
    NUT
  • 17
    2516-956 PANEL, FENDER - ASSEMBLY - RED (INC. 18-21)
    PANEL, FENDER - ASSEMBLY - RED (INC. 18-21)
  • 18
    1411-598 ...DECAL, REFLECTOR - RIGHT - RED
    ...DECAL, REFLECTOR - RIGHT - RED
  • 18
    1411-599 ...DECAL, REFLECTOR - LEFT - RED
    ...DECAL, REFLECTOR - LEFT - RED
  • 19
    2411-143 ...DECAL, WARNING - TIRE PRESSURE
    ...DECAL, WARNING - TIRE PRESSURE
  • 20
    0412-351 ...FOIL, PROTECTIVE
    ...FOIL, PROTECTIVE
  • 21
    1411-809 ...DECAL, PASSENGER
    ...DECAL, PASSENGER
  • 22
    1411-725 DECAL, "ARCTIC CAT"
    DECAL, "ARCTIC CAT"
  • 23
    2411-648 DECAL, SIDE - LOWER RIGHT
    DECAL, SIDE - LOWER RIGHT
  • 23
    2411-649 DECAL, SIDE - LOWER LEFT
    DECAL, SIDE - LOWER LEFT
