WIRING HARNESS ASSEMBLY для Arctic Cat 1000 MUD PRO LTD BLACK-ORANGE [A2012MLW1PUSY] - 2012 года выпуска`
-
№АртикулНазвание
-
10486-423 HARNESS, MAIN (INC. 2-10)HARNESS, MAIN (INC. 2-10)
-
20486-164 ...TETHER, ACCESSORY CONNECTOR...TETHER, ACCESSORY CONNECTOR
-
30430-085 ...COVER, FUSE BLOCK...COVER, FUSE BLOCK
-
40430-045 ...RELAY (4-PIN) - 20 AMP...RELAY (4-PIN) - 20 AMP
-
40430-033 ...RELAY (5-PIN) - 20 AMP...RELAY (5-PIN) - 20 AMP
-
50430-100 ...BREAKER, CIRCUIT - 15 AMP...BREAKER, CIRCUIT - 15 AMP
-
60430-037 ...HOLDER, FUSE...HOLDER, FUSE
-
70430-032 ...FUSE - 10 AMP...FUSE - 10 AMP
-
70430-031 ...FUSE - 15 AMP...FUSE - 15 AMP
-
70430-030 ...FUSE - 30 AMP...FUSE - 30 AMP
-
82411-464 ...DECAL, FUSE BLOCK...DECAL, FUSE BLOCK
-
90730-103 ...COVER, DIAGNOSTICS CONNECTOR...COVER, DIAGNOSTICS CONNECTOR
-
100430-086 ...SEAL...SEAL
-
111436-416 REPAIR KIT, CONNECTOR - TILT SENSORREPAIR KIT, CONNECTOR - TILT SENSOR
-
121436-415 REPAIR KIT, CONNECTOR - LCD GAUGEREPAIR KIT, CONNECTOR - LCD GAUGE
-
131436-289 REPAIR KIT, CONNECTOR - HEADLIGHTREPAIR KIT, CONNECTOR - HEADLIGHT
-
140423-493 NUT W/WASHERNUT W/WASHER
-
150409-064 SENSOR, TILTSENSOR, TILT
-
160123-802 WASHERWASHER
-
178468-425 SCREW, MACHINESCREW, MACHINE
-
180530-077 ECUECU
-
198476-620 SCREW, MACHINESCREW, MACHINE
-
200623-038 NUT W/WASHERNUT W/WASHER
-
212416-175 BRACKET, MOUNTING - ECUBRACKET, MOUNTING - ECU
-
220824-037 REGULATOR, VOLTAGEREGULATOR, VOLTAGE
-
238476-625 SCREW, MACHINESCREW, MACHINE
-
240824-071 COIL, IGNITION - ASSEMBLY (INC. 25)COIL, IGNITION - ASSEMBLY (INC. 25)
-
250824-049 ...CAP, SPARK PLUG...CAP, SPARK PLUG
-
262416-268 BRACKET, MOUNTING - COILBRACKET, MOUNTING - COIL
-
278476-616 SCREW, MACHINESCREW, MACHINE
-
280123-788 TIE, CABLE - 8 IN.TIE, CABLE - 8 IN.
-
280123-903 TIE, CABLE - 11.5 IN.TIE, CABLE - 11.5 IN.
-
290409-089 SWITCH, BRAKE - ASSEMBLYSWITCH, BRAKE - ASSEMBLY
