CARGO BOX AND TAILGATE ASSEMBLY для Arctic Cat PROWLER XTZ WHITE INTERNATIONAL [U2011P4W1POSW] - 2011 года выпуска

  • №
    Артикул
    Название
  • 1
    2506-205 TAILGATE ASSEMBLY - BLACK (INC. 2-9)
    TAILGATE ASSEMBLY - BLACK (INC. 2-9)
  • 2
    2406-365 ...PANEL, TAILGATE - INNER
    ...PANEL, TAILGATE - INNER
  • 3
    1406-927 ...SHAFT, PIVOT - TAILGATE
    ...SHAFT, PIVOT - TAILGATE
  • 4
    0623-784 ...SCREW, SELF-TAPPING
    ...SCREW, SELF-TAPPING
  • 5
    1506-704 ...BRACE, TAILGATE
    ...BRACE, TAILGATE
  • 6
    0423-101 ...SCREW, SHOULDER
    ...SCREW, SHOULDER
  • 7
    2506-056 ...LATCH, TAILGATE - ASSEMBLY
    ...LATCH, TAILGATE - ASSEMBLY
  • 8
    1406-706 ...BUSHING
    ...BUSHING
  • 9
    2406-369 ...PANEL, TAILGATE - OUTER - BLACK
    ...PANEL, TAILGATE - OUTER - BLACK
  • 10
    2411-449 DECAL, "ARCTIC CAT"
    DECAL, "ARCTIC CAT"
  • 11
    8476-625 SCREW, MACHINE
    SCREW, MACHINE
  • 12
    0487-045 CABLE, TAILGATE
    CABLE, TAILGATE
  • 13
    8050-217 WASHER
    WASHER
  • 14
    8476-620 SCREW, MACHINE
    SCREW, MACHINE
  • 15
    0624-250 NUT, LOCK
    NUT, LOCK
  • 16
    8424-602 NUT
    NUT
  • 17
    2506-664 STRIKER, TAILGATE - RIGHT
    STRIKER, TAILGATE - RIGHT
  • 17
    2506-665 STRIKER, TAILGATE - LEFT
    STRIKER, TAILGATE - LEFT
  • 18
    8474-630 SCREW, MACH-TSFH M6X1.0X30 CL8.8 BLK
    SCREW, MACH-TSFH M6X1.0X30 CL8.8 BLK
  • 19
    0417-006 STRIP, FOAM
    STRIP, FOAM
  • 20
    2406-916 BOX, CARGO - BLACK
    BOX, CARGO - BLACK
  • 21
    1411-119 DECAL, WARNING - CARGO
    DECAL, WARNING - CARGO
  • 22
    0423-623 BOLT, CARRIAGE
    BOLT, CARRIAGE
  • 23
    1506-933 PLATE, RETAINER
    PLATE, RETAINER
  • 24
    8424-802 NUT
    NUT
  • 25
    1506-539 BRACKET, TAILGATE
    BRACKET, TAILGATE
  • 26
    0417-011 FOAM, CARGO BOX(1.625 X 2 X 6.5)
    FOAM, CARGO BOX(1.625 X 2 X 6.5)
  • 27
    0417-010 FOAM, CARGO BOX (1.75 X 2 X 8)
    FOAM, CARGO BOX (1.75 X 2 X 8)
  • 28
    1406-762 PANEL, BOX - RIGHT - BLACK
    PANEL, BOX - RIGHT - BLACK
  • 28
    1406-761 PANEL, BOX - LEFT - BLACK
    PANEL, BOX - LEFT - BLACK
  • 29
    2411-454 DECAL, BOX - RIGHT
    DECAL, BOX - RIGHT
  • 29
    2411-455 DECAL, BOX - LEFT
    DECAL, BOX - LEFT
  • 30
    1411-128 DECAL, REFLECTOR - RIGHT
    DECAL, REFLECTOR - RIGHT
  • 30
    1411-129 DECAL, REFLECTOR - LEFT
    DECAL, REFLECTOR - LEFT
  • 31
    0423-342 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 32
    1506-776 BRACKET, FENDER SUPPORT - RIGHT
    BRACKET, FENDER SUPPORT - RIGHT
  • 32
    2506-927 BRACKET, FENDER SUPPORT - LEFT
    BRACKET, FENDER SUPPORT - LEFT
  • 33
    4506-108 FENDER, REAR - ASSEMBLY - UPPER RIGHT - WHITE (INC. 34-36)
    FENDER, REAR - ASSEMBLY - UPPER RIGHT - WHITE (INC. 34-36)
  • 33
    4506-109 FENDER, REAR - ASSEMBLY - UPPER LEFT - WHITE (INC. 34-36)
    FENDER, REAR - ASSEMBLY - UPPER LEFT - WHITE (INC. 34-36)
  • 34
    0417-008 ...PAD, FOAM .125 IN
    ...PAD, FOAM .125 IN
  • 35
    0417-007 ...STRIP, FOAM .125 IN
    ...STRIP, FOAM .125 IN
  • 36
    2516-037 ...RING, TRIM
    ...RING, TRIM
  • 37
    1411-120 DECAL, WARNING - PINCH POINT
    DECAL, WARNING - PINCH POINT
  • 38
    0423-540 NUT, LOCK
    NUT, LOCK
  • 39
    2516-178 BRACKET, CARGO BOX LATCH
    BRACKET, CARGO BOX LATCH
  • 40
    8476-616 SCREW, MACHINE
    SCREW, MACHINE
