WHEEL AND TIRE ASSEMBLY для Arctic Cat PROWLER HDX TIMBER CAMO [U2011P5T1PUSH] - 2011 года выпуска

  • №
    Артикул
    Название
  • 1
    0423-557 SCREW,SHOULDER-W/LOCTITE
    SCREW,SHOULDER-W/LOCTITE
  • 2
    1436-418 DISC, BRAKE - FRONT
    DISC, BRAKE - FRONT
  • 2
    1436-164 DISC, BRAKE - REAR
    DISC, BRAKE - REAR
  • 3
    1502-433 HUB, WHEEL - FRONT (INC. 4)
    HUB, WHEEL - FRONT (INC. 4)
  • 3
    1502-437 HUB, WHEEL - REAR (INC. 4)
    HUB, WHEEL - REAR (INC. 4)
  • 3
    1502-437 HUB, WHEEL - REAR (INC. 4)
    HUB, WHEEL - REAR (INC. 4)
  • 4
    0402-974 ...STUD
    ...STUD
  • 5
    0423-407 PIN,COTTER-1/8X1-1/2
    PIN,COTTER-1/8X1-1/2
  • 6
    0423-607 NUT, CASTLE
    NUT, CASTLE
  • 7
    1402-732 WHEEL,FRONT - ALUMINUM (14X6.5) (INC. 8)
    WHEEL,FRONT - ALUMINUM (14X6.5) (INC. 8)
  • 8
    1402-736 ...CAP, WHEEL
    ...CAP, WHEEL
  • 9
    0402-064 STEM, VALVE (INC. 10)
    STEM, VALVE (INC. 10)
  • 10
    0402-140 ...CAP, VALVE STEM
    ...CAP, VALVE STEM
  • 11
    0423-618 NUT, LUG - CHROME
    NUT, LUG - CHROME
  • 12
    1402-860 TIRE - FRONT, DURO RED EAGLE NHS(26X10R14)
    TIRE - FRONT, DURO RED EAGLE NHS(26X10R14)
  • 13
    1402-918 WHEEL,REAR-ALUMINUM (14X8.0) (INC. 8)
    WHEEL,REAR-ALUMINUM (14X8.0) (INC. 8)
  • 14
    1402-861 TIRE - REAR,DURO RED EAGLE NHS(26X12R14)
    TIRE - REAR,DURO RED EAGLE NHS(26X12R14)
