PASSENGER SEAT AND BACKREST ASSEMBLY для Arctic Cat TRV 700 H1 EFI METALLIC BLACK [A2010TBT4EUSO] - 2010 года выпуска`
-
№АртикулНазвание
-
12506-956 SEAT, PASSENGER - ASSEMBLY (INC. 2-15)SEAT, PASSENGER - ASSEMBLY (INC. 2-15)
-
22506-940 ...SEAT, PASSENGER - SUB-ASSEMBLY (INC. 3-6)...SEAT, PASSENGER - SUB-ASSEMBLY (INC. 3-6)
-
32506-944 ......COVER, SEAT - PASSENGER......COVER, SEAT - PASSENGER
-
42506-942 ......FOAM, SEAT - PASSENGER......FOAM, SEAT - PASSENGER
-
52406-110 ......BASE, SEAT - INNER......BASE, SEAT - INNER
-
60624-263 ......STAPLE......STAPLE
-
72406-044 ...BASE, SEAT - PASSENGER...BASE, SEAT - PASSENGER
-
80411-814 ...DECAL, "ARCTIC CAT"...DECAL, "ARCTIC CAT"
-
92406-834 ...HANDHOLD, PASSENGER - RIGHT...HANDHOLD, PASSENGER - RIGHT
-
92406-835 ...HANDHOLD, PASSENGER - LEFT...HANDHOLD, PASSENGER - LEFT
-
108432-802 ...NUT, LOCK...NUT, LOCK
-
118468-830 ...SCREW, MACHINE...SCREW, MACHINE
-
122516-040 ...BRACKET, SEAT SUPPORT - ASSEMBLY...BRACKET, SEAT SUPPORT - ASSEMBLY
-
132406-895 ...END CAP, SEAT SUPPORT...END CAP, SEAT SUPPORT
-
140423-538 ...SCREW, SELF-TAPPING...SCREW, SELF-TAPPING
-
158427-602 ...NUT, LOCK...NUT, LOCK
-
168408-816 SCREW, CAPSCREW, CAP
-
172516-020 BACKREST ASSEMBLY (INC. 18-19)BACKREST ASSEMBLY (INC. 18-19)
-
182516-141 ...COVER, BACKREST...COVER, BACKREST
-
192516-018 ...FOAM, BACKREST...FOAM, BACKREST
