WINCH ASSEMBLY для Arctic Cat 500 AUTO (ARCTIC CAT GREEN) [A2008IBM4BUSZ] - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    1441-704 WINCH (INC. 2-3)
    WINCH (INC. 2-3)
  • 2
    0441-061 ...CABLE, WINCH
    ...CABLE, WINCH
  • 3
    1411-826 ...DECAL, WINCH-ARCTIC CAT/WARN(3.0 RT/XT)
    ...DECAL, WINCH-ARCTIC CAT/WARN(3.0 RT/XT)
  • 4
    0441-426 HOOK, WINCH W/STRAP - ASSEMBLY (INC. 5-7)
    HOOK, WINCH W/STRAP - ASSEMBLY (INC. 5-7)
  • 5
    1441-131 ...HOOK, WINCH W/STRAP AND WARNING TAG
    ...HOOK, WINCH W/STRAP AND WARNING TAG
  • 6
    1441-130 ...PIN, CLEVIS
    ...PIN, CLEVIS
  • 7
    1441-129 ...COTTER PIN
    ...COTTER PIN
  • 8
    0441-403 ROLLER, WINCH
    ROLLER, WINCH
  • 8
    8468-820 SCREW, MACHINE M8X1.25X20 CL8.8 BLK
    SCREW, MACHINE M8X1.25X20 CL8.8 BLK
  • 10
    8051-246 WASHER, LOCK - .318X.596X.097 Z & C
    WASHER, LOCK - .318X.596X.097 Z & C
  • 11
    1623-131 SCREW, CAP - HH 5/16-18 X 1" GR 5 Z & C
    SCREW, CAP - HH 5/16-18 X 1" GR 5 Z & C
  • 12
    0445-068 CABLE, WINCH/SOLENOID (7" YELLOW)
    CABLE, WINCH/SOLENOID (7" YELLOW)
  • 13
    0445-069 CABLE, WINCH/SOLENOID (10" BLUE)
    CABLE, WINCH/SOLENOID (10" BLUE)
  • 14
    0123-788 CABLE TIE - 8.5/7.5/7.4
    CABLE TIE - 8.5/7.5/7.4
  • 15
    1441-112 CABLE, SOLENOID/BATTERY - BLACK
    CABLE, SOLENOID/BATTERY - BLACK
  • 16
    1441-113 CABLE, SOLENOID/BATTERY - RED
    CABLE, SOLENOID/BATTERY - RED
  • 17
    0441-060 BOOT, TERMINAL
    BOOT, TERMINAL
  • 18
    0409-066 SOLENOID, WINCH-ASSY
    SOLENOID, WINCH-ASSY
  • 19
    0623-038 NUT W/WASHER
    NUT W/WASHER
  • 20
    8476-625 SCREW, MACHINE M6X1.0X25 Z & Y
    SCREW, MACHINE M6X1.0X25 Z & Y
  • 21
    0409-087 SWITCH, WINCH-HARNESS ASS'Y
    SWITCH, WINCH-HARNESS ASS'Y
  • 22
    0409-034 HOLDER, CONTROL SWITCH (500 A)
    HOLDER, CONTROL SWITCH (500 A)
  • 23
    0409-106 COVER, SWITCH
    COVER, SWITCH
  • 24
    0423-593 WASHER, FLAT-Z & B (11MM ODX 5.5MM IDX 1.8)
    WASHER, FLAT-Z & B (11MM ODX 5.5MM IDX 1.8)
  • 25
    0423-382 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 26
    8464-560 SCREW, MACHINE - PHTRH M5-.8X12 Z & BLK
    SCREW, MACHINE - PHTRH M5-.8X12 Z & BLK
