FRAME AND RELATED PARTS для Arctic Cat 400 MAN (GREEN) [A2008ICH4AUSG] - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    2506-549 FRAME, MAIN
    FRAME, MAIN
  • 2
    8409-020 SCREW, CAP
    SCREW, CAP
  • 3
    1506-596 CHANNEL, BUMPER MOUNTING - RIGHT (BLACK)
    CHANNEL, BUMPER MOUNTING - RIGHT (BLACK)
  • 3
    0506-653 CHANNEL, BUMPER MOUNTING - LEFT (BLACK)
    CHANNEL, BUMPER MOUNTING - LEFT (BLACK)
  • 4
    1506-686 BRACKET, MOUNTING - BUMPER - RIGHT (BLACK)
    BRACKET, MOUNTING - BUMPER - RIGHT (BLACK)
  • 4
    1506-687 BRACKET, MOUNTING - BUMPER - LEFT (BLACK)
    BRACKET, MOUNTING - BUMPER - LEFT (BLACK)
  • 5
    8408-816 SCREW, CAP
    SCREW, CAP
  • 6
    1506-684 BUMPER, FRONT-BLACK
    BUMPER, FRONT-BLACK
  • 7
    1406-868 FACIA, BUMPER - FRONT
    FACIA, BUMPER - FRONT
  • 8
    0423-101 SCREW, BODY
    SCREW, BODY
  • 9
    8428-002 NUT, LOCK
    NUT, LOCK
  • 10
    1506-429 BRACE, A-ARM (BLACK)
    BRACE, A-ARM (BLACK)
  • 11
    8409-025 SCREW, CAP
    SCREW, CAP
  • 12
    1406-030 PANEL, BELLY
    PANEL, BELLY
  • 13
    1506-067 FOAM, FRAME
    FOAM, FRAME
  • 14
    0406-289 PAD, FRAME
    PAD, FRAME
  • 15
    8424-802 NUT, FLANGE
    NUT, FLANGE
  • 16
    8409-016 SCREW, CAP
    SCREW, CAP
  • 17
    1506-659 FOOTREST - RIGHT (BLACK)
    FOOTREST - RIGHT (BLACK)
  • 17
    1506-660 FOOTREST - LEFT (BLACK)
    FOOTREST - LEFT (BLACK)
  • 18
    2506-426 ROD, SUPPORT (BLACK)
    ROD, SUPPORT (BLACK)
