WIRING HARNESS ASSEMBLY для Arctic Cat 500 4X4 AUTO (GREEN) [A2002ATM4BUSG] - 2002 года выпуска

  • №
    Артикул
    Название
  • 1
    0486-078 HARNESS, MAIN (INC. 2)
    HARNESS, MAIN (INC. 2)
  • 2
    0486-029 ...DIODE (START IN GEAR)
    ...DIODE (START IN GEAR)
  • 3
    0486-004 HARNESS, 12V RECEPTACLE
    HARNESS, 12V RECEPTACLE
  • 4
    0445-022 RECEPTACLE, 12V
    RECEPTACLE, 12V
  • 5
    3530-028 REGULATOR, VOLTAGE
    REGULATOR, VOLTAGE
  • 6
    3530-032 CDI UNIT
    CDI UNIT
  • 7
    0406-867 BRACKET, CDI UNIT
    BRACKET, CDI UNIT
  • 8
    8476-616 SCREW, MACHINE
    SCREW, MACHINE
  • 9
    0409-009 SWITCH, BRAKE
    SWITCH, BRAKE
  • 10
    3530-027 COIL, IGNITION - ASSEMBLY
    COIL, IGNITION - ASSEMBLY
  • 11
    3430-009 SEAL, HIGH TENSION CORD
    SEAL, HIGH TENSION CORD
  • 12
    3430-007 CAP, SPARK PLUG
    CAP, SPARK PLUG
  • 13
    3430-008 SEAL, SPARK PLUG
    SEAL, SPARK PLUG
  • 14
    0586-003 DIODE ASSEMBLY
    DIODE ASSEMBLY
  • 15
    3530-008 RELAY, NEUTRAL START - ASSEMBLY
    RELAY, NEUTRAL START - ASSEMBLY
  • 16
    3530-001 RELAY, STARTER MOTOR - ASSEMBLY (INC. 17-18)
    RELAY, STARTER MOTOR - ASSEMBLY (INC. 17-18)
  • 17
    0630-098 ...FUSE, 30 AMP
    ...FUSE, 30 AMP
  • 18
    3530-010 ...COVER, STARTER MOTOR RELAY
    ...COVER, STARTER MOTOR RELAY
  • 19
    3423-020 SCREW, CAP
    SCREW, CAP
  • 20
    0445-003 CABLE, BATTERY/ELECTRIC START
    CABLE, BATTERY/ELECTRIC START
  • 21
    0445-020 CABLE, BATTERY/GROUND
    CABLE, BATTERY/GROUND
  • 22
    0445-019 CABLE, BATTERY/ELECTRIC START RELAY
    CABLE, BATTERY/ELECTRIC START RELAY
  • 23
    0645-019 BOOT, TERMINAL
    BOOT, TERMINAL
  • 24
    0123-788 CABLE TIE - 7 IN.
    CABLE TIE - 7 IN.
  • 25
    0123-903 CABLE TIE - 11.5 IN.
    CABLE TIE - 11.5 IN.
  • 26
    8476-620 SCREW, MACHINE
    SCREW, MACHINE
  • 27
    0402-168 RETAINER, BRAKE SWITCH
    RETAINER, BRAKE SWITCH
